Programming Guide Mitras LX7
EN 2016-11-21 15
High Output - Maximum light output with slightly lower efficiency
Furthermore, the maximum Output power (10% - 100%) of all channels can be set.
With this, it is possible to dim down all channels equally without having to change the
individual illumination runs.
The maximum Temperature (55 °C - 65 °C) determines from which heat sink temperature the
power is reduced to prevent a further temperature increase.
The maximum Fan speed (60% - 100%) determines how fast the fans are allowed to run at
most. The setting depends on whether a low noise level or a maximum light output should
have priority.
4.4 Wireless
Luminaires can communicate with one another, e.g. to synchronize lighting processes via the
integrated radio module.
The following modes can be selected:
Standalone - This lamp works alone, the radio module is not used.
Master - This lamp controls slave lights of the same group.
Slave - This light is controlled by a master in the same group (many settings are then not
required because they are carried out by the master).
Wireless address – All wireless devices of a group (a group consists of a Master and at least
one Slave) must have different wireless addresses (Example: Master = 1, first Slave = 2,
second Slave =3 etc.)
Wireless channel (11 – 26) – All wireless devices of a group must use the same wireless channel.
The wireless channel can be changed in the event of interference from other transmitters (e.g.
WLAN or Bluetooth) or when several independent Mitras LX7 groups are to be operated
