Programming Guide Mitras LX7
EN 2016-11-21 8
First you have to specify whether the luminaires should run in Automatic Mode or not. If not,
this illumination channel is in Manual mode and not dimmed automatically.
In the next step the illumination run is to be determined.
Enter the number of dim-points for which you want to adjust the brightness (up to 24).
For each dim-point, set the following:
Time - At this time, the lighting channel should have the following brightness
Brightness (0% - 100%) - Brightness of the illumination channel at this time
The brightness curve between the individual dim-points is calculated
automatically.
If you would like to have the moon phase simulation affect this illumination channel, tick the
Moon checkbox.
2.2 Manual Illumination
The setting of the manual brightness is only available for master and stand-alone luminaires.
If the luminaire is a master, the corresponding slave lamps are synchronously controlled.
This menu is mainly used for test and diagnostic purposes. With the arrow keys on the left
and the arrow on the right, you can select the lighting channel whose brightness you want to
adjust, 4 channels are displayed simultaneously. Use the up/down arrows to make the
selected channel brighter or darker.
The symbols displayed to the left and right of the selected channel have the following
meanings:
Dimmable only upwards (at 0%)
Dimmable only downwards (at 100%)
Dimmable in both directions
