LPS10
- 3 -
V1.0
1 INTRODUCTION
PYRAsense series pyranometers measure the global irradiance on a flat surface
(W/m
2
), sum of direct solar irradiance and diffuse irradiance.
The PYRAsense LPS10 series falls within the Spectrally Flat Class A pyranometers
according to the ISO 9060:2018 standard and meets the requirements of the WMO
“Guide to Instruments and Methods of Observation”.
The internal temperature, relative humidity and pressure diagnostic sensors allow
keeping the pyranometer operating conditions under control all the time and foresee
any maintenance intervention in advance, thus ensuring always reliable measure-
ments.
The integrated bubble level and the adjustable feet facilitate horizontal positioning
during installation. As option, they can be equipped with a tilt sensor (option T in the
ordering code) which, in addition to facilitating the installation of the pyranometer,
allows continuous monitoring of the correct installation.
The various models are distinguished by the type of output available and by the pres-
ence or absence of the "tilt" sensor:
Output
Tilt
Model
Digital RS485
Modbus-RTU
Analog
LPS10M00
√
--
--
LPS10M0T √
LPS10MA0
√
Configurable 4…20 mA (default),
0…20 mA, 0…1 V, 0…5 V or 0…10 V
--
LPS10MAT √
The irradiance range for the analog output is user configurable (default, 0…2000
W/m
2
).
The pyranometers are factory calibrated in accordance with the ISO 9847:2023 (Type
A1) standard: ”Calibration of pyranometers by comparison to a reference
pyranometer”. The calibration is performed by comparison with the reference sample
calibrated annually at WRC (World Radiation Center).
The DATAsense PC application software, downloadable from the Delta OHM website,
allows configuring the sensor (e.g., Modbus parameters, measuring range for the
analog output, etc.), monitor the measurements in real time, even graphically for the
irradiance, and save the values detected during the connection in a file.
