7 MODBUS-RTU PROTOCOL
By default, the pyranometer has Modbus address 1 and communication parameters
19200, 8E1. The address and the communication parameters can be changed by using
the appropriate serial commands of the proprietary protocol or, alternatively, directly
with Modbus commands by changing the value of the Holding Registers described lat-
er.
The Modbus-RTU protocol is active after a few seconds from the sensor power on.
Below is the list of registers.
Input Registers:
Address Description Format
MEASUREMENTS
1
Temperature compensated irradiance in W/m
2
(x10)
(it takes into account the change in sensor sensitivity as
temperature changes)
32-bit Integer
3
Nominal irradiance in W/m
2
(x10)
(calculated considering the sensor nominal sensitivity at the
calibration temperature: ∼ 23 °C)
32-bit Integer
6 Internal relative humidity in % (x10) 16-bit Integer
7 Internal temperature in the set unit of measurement (x10) 16-bit Integer
8 Internal pressure in hPa (x10) 16-bit Integer
9 Signal in mV generated by the thermopile (x1000) 32-bit Integer
11 Tilt angle (only LPS10MxT) (x10) 16-bit Integer
PYRANOMETER GENERAL INFORMATION
16…25 Model (20 characters) String
26…35 Sub-model (20 characters) String
36…39 Serial number (8 characters) String
40…43 Firmware revision (8 characters) String
44…47 Hardware revision (8 characters) String
CALIBRATION HISTORY
50 Sensitivity of last calibration in µV/Wm
-2
(x1000) 32-bit Integer
52…55 Date of last calibration (yyyymmdd) String
56 Sensitivity of historical calibration 1 in µV/Wm
-2
(x1000) 32-bit Integer
58…61 Date of historical calibration 1 (yyyymmdd) String
62 Sensitivity of historical calibration 2 in µV/Wm
-2
(x1000) 32-bit Integer
64…67 Date of historical calibration 2 (yyyymmdd) String
68 Sensitivity of historical calibration 3 in µV/Wm
-2
(x1000) 32-bit Integer
70…73 Date of historical calibration 3 (yyyymmdd) String
74 Sensitivity of historical calibration 4 in µV/Wm
-2
(x1000) 32-bit Integer
76…79 Date of historical calibration 4 (yyyymmdd) String
