GHM Delta OHM PYRAsense LPS10 Series User Manual

LPS10 - 4 - V1.0
2 TECHNICAL SPECIFICATIONS
Sensor Thermopile
Measuring range
-200…4000 W/m
2
The irradiance range for the analog output is configurable
(default 0…2000 W/m
2
)
Resolution 0.1 W/m
2
Viewing angle 2π sr
Spectral range (50%) 283…2800 nm
Output
RS485 Modbus-RTU (isolated)
Optional additional analog output configurable 4…20 mA
(default), 0…20 mA, 0…1 V, 0…5 V or 0…10 V
Power supply
7…30 Vdc for RS485 output
10…30 Vdc for analog output (except 0…10 V)
15…30 Vdc for 0…10 V output
Consumption
15 mA @ 24 Vdc
Connection
5-pole M12 (LPS10M0x)
8-pole M12 (LPS10MAx)
Weight 620 g approx.
Operating conditions -40…+80 °C / 0…100 %RH
Bubble level accuracy
(For the Tilt sensor accuracy see the
sensor specifications below)
< 0.2°
Protection degree IP 67
Materials
Housing: anodized aluminium
Screen: ASA
Dome: optical glass
MTBF > 10 years
Dimensions (mm)
