SPECIFICATIONS
©Ghost Controls 2018
SPECIFICATIONS
■ Compliance: The operator is system certified to be in compliance
with UL325 Standard, 7th Edition
■ System Operating Voltage: 12 VDC
■ System Battery Type: Battery Box Kit (ABBT) included
■ System Current: 1-2 Amps is typical when active.
Standby is 20 milliamps
■ Operator Arm Maximum Stroke Distance: 23"
■ Maximum Gate Length: 20'
■ Operator Opening Speed: 90 degrees in approximately 15 seconds
■ Maximum Operator Opening Range: 110 degrees
■ Linear Actuator Operating Temperature: -5°F to 160°F
Maximum Gate
Length and
Weight
Max
900 lbs.
800 lbs.
700 lbs.
600 lbs.
500 lbs.
400 lbs.
350 lbs.
325 lbs.
300 lbs.
5' 6' 8' 10' 12' 14' 16' 18' 20'
DTP1 DTP1
DTP1
DTP1
DTP1
DTP1
DTP1
DTP1
DTP1
1000 lbs.
SPECIFICATIONS
DTP1 GATE OPERATOR KIT
