18
4
取出 LSC 調整軸
Remove the LSC adjustment knob.
5
使用 24MM 套筒旋開阻尼室螺母
Unthread the damper side nut using a 24mm
socket and turning in a counterclockwise
direction.
6
取出阻尼棒後，使用 5 號六角板手及萬用鉗
拆開螺絲，分離阻尼棒。
註：請小心夾持阻尼棒並包覆緩衝物以避免造
成損傷。
參考阻尼側組裝章節安裝阻尼。
Remove damper cartridge.
Gently hold the damper cartridge and unthread
the bolt using a 5 mm hex and universal grip
pliers.
Note: Grip the damper cartridge carefully to
avoid damage.
Refer to damper side assembly section to re-
assemble.
