GIGA-BYTE TECHNOLOGY B450 AORUS ELITE User Manual

Storage Interface  - 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe3.0x4/x2SSDsupport)(M2A_SOCKET)
 - 1xM.2connector(Socket3,Mkey,type2242/2260/2280PCIe3.0x2SSD
support)(M2B_SOCKET)
 6 x SATA 6Gb/s connectors
 SupportforRAID0,RAID1,andRAID10
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB  Chipset:
- 2 x USB 3.1 Gen 1 ports available through the internal USB header
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB headers)
 Integrated in the APU:
- 4 x USB 3.1 Gen 1 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 2 x M.2 Socket 3 connectors
 6 x SATA 6Gb/s connectors
 1 x CPU fan header
 3 x system fan headers
 1xCPUcoolerLEDstrip/RGBLEDstripextensioncableheader
 1xRGB(RGBW)LEDstripheader
 2xdigitalLEDstripheaders
 2xdigitalLEDstrippowerselectjumpers
 1 x front panel header
 1 x front panel audio header
 1xS/PDIFOutheader
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module
only)
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1xDVI-Dport
 1xHDMIport
 4 x USB 3.1 Gen 1 ports
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 6 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
- 7 -
