Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1-7 Internal Connectors
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) SATA3 0/1/2/3/4/5
6) M2Q_SB/M2A_SB
7) SPDIF_O
8) F_PANEL
9) F_AUDIO
10) F_U32
11) F_USB1/F_USB2
12) COMA
13) LPT
14) SPI_TPM
15) THB_C1/THB_C2
16) CLR_CMOS
17) BAT
816
4
2
5
10
15
9 13
1
4
12
4
17
7
11 14
3
6
6
