- 17 -
2-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) LED_C
6) D_LED
7) SATA3 0/1/2/3
8) M2A_CPU/M2P_CPU/M2X_SB
9) F_PANEL
10) F_AUDIO
11) F_U32C
12) F_U32
13) F_USB1/F_USB2/F_USB3
14) COM
15) SPI_TPM
16) BAT
17) CLR_CMOS
2
7
4
13
1
5
9
3
10
8
8
6
414
17
8
11
12
15
16
16
