Gigabyte G1.Assassin User Manual

- 11 - Hardware Installation
USB South Bridge: 
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
1 x  Renesas D720200 chip and 2 x VLI VL810 hubs:
- Up to 8 USB 3.0/2.0 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
* The USB 2.0 signals of the USB 3.0/2.0 ports are from the South Bridge.
Internal
Connectors
1 x 24-pin ATX main power connector 
2 x 8-pin ATX 12V power connectors 
2 x 4-pin PCIe 12V power connectors 
2 x SATA 6Gb/s connectors 
6 x SATA 3Gb/s connectors 
1 x CPU fan header 
1 x system fan header 
3 x fan headers 
1 x front panel header 
1 x front panel audio header 
1 x S/PDIF Out header 
2 x USB 2.0/1.1 headers 
2 x USB 3.0/2.0 headers 
1 x clearing CMOS jumper 
1 x Quick Boost button header 
1 x heatsink LED power connector 
Back Panel
Connectors
1 x PS/2 keyboard port 
1 x PS/2 mouse port 
1 x optical S/PDIF Out connector 
1 x coaxial S/PDIF Out connector 
4 x USB 2.0/1.1 ports 
4 x USB 3.0/2.0 ports 
1 x RJ-45 port 
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker 
Out, Line In/Mic In, Line Out)
I/O Controller iTE IT8720 chip 
Hardware
Monitor
System voltage detection 
CPU/System temperature detection 
CPU/System fan speed detection 
CPU overheating warning 
CPU/System fan fail warning 
CPU/System fan speed control 
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 2x16Mbitash 
Use of licensed AWARD BIOS 
Support for DualBIOS 
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b 

Gigabyte G1.Assassin Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Number of memory slots	6
Maximum internal memory	24 GB
Supported memory clock speeds	800, 1066, 1333, 2200 MHz
Supported memory module capacities	4GB
System bus rate	6.4 GT/s
Processor socket	Socket B (LGA 1366)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
Processor system buses supported	800, 1066, 1333 MHz
USB 2.0 connectors	3
Number of SATA connectors	8
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Controller interface type	Marvell 88SE9182
Controller 2nd interface type	JMicron JMB362
Audio chip	Realtek ALC889
Component for	PC
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows 7, Vista, XP
On-board graphics card	No
Parallel processing technology support	3-Way SLI
LAN controller	Bigfoot Killer E2100
Ethernet interface type	Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b
BIOS memory size	32 Mbit
RAID levels	0, 1, 5, 10, JBOD

Weight and Dimensions

Depth	263 mm
Width	305 mm
