G1.Assassin Motherboard Block Diagram
PS/2 KB/Mouse
LGA1366
CPU
QPI
Interface
Intel
®
X58
IOH CLK (133 MHz)
Intel
®
ICH10R
PCI Bus
IT8720
CPU CLK+/- (133 MHz)
6 SATA 3Gb/s
Dual BIOS
8 USB 2.0/1.1
LPC
Bus
DDR3 2200/1333/1066/800 MHz
Center/Subwoofer Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Side Speaker Out
Surround Speaker Out
CREATIVE
CA20K2
PCI Express Bus
Dual/3 Channel Memory
PCIe CLK
(100 MHz)
PCIe CLK
(100 MHz)
Marvell
88SE9182
2 SATA 6Gb/s
x2
PCIe CLK
(100 MHz)
x1
LAN
RJ45
Marvell
88E1118R phy
2 PCI
Express x1
x1x1
1 PCI Express x16
2 PCI Express x8
x8
x16
1 PCI Express x16
x16
Switch
2 PCI Express x8
x8
Switch
PCI Express Bus
x1
VLI VL810
Hub
Renesas
D720200
8 USB 3.0/2.0
VLI VL810
Hub
1 PCI
x1
PCI CLK
(33 MHz)
BigFoot Killer E2100
