Gigabyte GA-6LXSV User Manual

Hardware Installation
- 18 -
Link
Activity LED
Link
Activity LED
Link
Activity LED
Speed LED
Speed LED
Speed LED
10/100 LAN Port
10/100/1000 LAN Port
Link/Activity LED:
Link/Activity LED:
MLAN Speed LED:
I210 Speed LED:
State Description
Green On 100 Mbps data rate
Green Blink 10 Mbps or 100 Mbps
data rate
Off 10 Mbps data rate
State Description
Yellow On 1 Gbps data rate
Yellow Blink Identify 1 Gbps data
rate
Green On 100 Mbps data rate
Green Blink Identify 100 Mbps data
rate
Off 10 Mbps data rate
State Description
On Link bet ween system and network or no
access
Blinking Data transmission or receiving is occurring
Off No data transmission or receiving is occurring
State Description
On Link bet ween system and network or no
access
Blinking Data transmission or receiving is occurring
Off No data transmission or receiving is occurring
• When removing the cable connected to a back panel connector, rst remove the cable from your
device and then remove it from the motherboard.
• When removing the cable, pull it straight out from the connector. Do not rock it side to side to
prevent an electrical short inside the cable connector.
