BIOS Setup - 50 -
SATA Controller(s)
Enable/Disable the SATA controller.
Options available: Enabled/Disabled. Default setting is Enabled.
SATA Mode Selection
Select the on chip SATA type.
RAID Mode: When set to RAID, the SATA controllerenables both its RAID and AHCI functions. You will
be allows access the RAID setup utility at boot time.
AHCI Mode: When set to AHCI,the SATA controller enables its AHCI functionality. Then the RAID
function is disabled and cannot be access the RAID setup utility at boot time.
Options available: RAID/AHCI/Disabled. Default setting is AHCI Mode.
SATA Test Mode
Enable/Disable SATA Test Mode.
Options available: Enabled/Disabled. Default setting is Disabled.
Aggressive LPM Support
Enable PCH to aggressively enter link power state.
Options available: Enabled/Disabled. Default setting is Enabled.
SATA Controller Speed
Indicates the maximum speed that the SATA controller can support.
Options available: Default/Gen1/Gen2/Gen3. Default setting is Default.
SoftwareFeatureMaskConguration
Press [Enter] for conguration of advanced items.
Serial Port 0/1/2/3/4/5
The category identies Serial ATA type of hard disk that are installed in the computer.
System will automatically detect HDD type.
Port 0/1/2/3/4/5
Enable/Disable Port 0/1/2/3/4/5.
Options available: Enabled/Disabled. Default setting is Enabled.
Hot Plug (for Serial SATA Port 0/1/2/3/4/5)
Enable/Disable Hot Plug support for Serial ATA Port 0/1/2/3/4/5.
Options available: Enabled/Disabled. Default setting is Disabled.
External SATA (for Serial SATA Port 0/1/2/3/4/5)
Enable/Disable External SATA support for Serial ATA Port 0/1/2/3/4/5.
Options available: Enabled/Disabled. Default setting is Disabled.
SATA Device Type (for Serial SATA Port 0/1)
Dene the SATA Device for Serial ATA Port 0/1.
Options available: Hard Disk Drive/Solid State Drive. Default setting is Disabled.
Spin Up Device (for Serial SATA Port 0/1/2/3/4/5)
On an edge detect from 0 to 1, the PCH starts a COMreset initialization to the device.
Options available: Enabled/Disabled. Default setting is Disabled.
