- 23 -
2-3 MBIntelligentTweaker(M.I.T.)
Whether the system will work stably with the overclock/overvoltage settings you made is depen-
dent on your overall system congurations. Incorrectly doing overclock/overvoltage may result in
damage to CPU, chipset, or memory and reduce the useful life of these components. This page is
for advanced users only and we recommend you not to alter the default settings to prevent system
instability or other unexpected results. (Inadequately altering the settings may result in system's
failure to boot. If this occurs, clear the CMOS values and reset the board to default values.)
When the System Voltage Optimized item blinks in red, it is recommended that you set the
System Voltage Control item to Auto to optimize the system voltage settings.
(Note) This item is present only when you install a CPU that supports this feature.
IGXConguration
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
MB Intelligent Tweaker(M.I.T.)
IGXConguration [PressEnter]
CPUClockRatio [Auto] 2400Mhz
Core Performance Boost
(Note)
[Enabled]
CPB Ratio
(Note)
[Auto] 2400Mhz
CPUHostClockControl [Auto]
x CPU Host Clock 100
PCIeSpreadSpectrum [Disabled]
SetMemoryClock [Auto]
x Memory Clock x6.66 1333Mhz
DRAMConguration [PressEnter]
********
System Voltage Optimized
********
SystemVoltageControl [Auto]
x DDR3 Voltage Control Auto
x FCH Voltage Control Auto
x APU VDDP Voltage Control Auto
x CPU VCORE NB Control Auto
x CPU VCORE Control Auto
Normal CPU Vcore 1.3875V

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
IGXConguration

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

UMAFrameBufferSize [Auto]
VGACoreClockcontrol [Auto]
x VGA Core Clock(MHz) 600
UMAFrameBufferSize
Frame buffer size is the total amount of system memory allocated solely for the onboard graphics con-
troller. MS-DOS, for example, will use only this memory for display. Options are: Auto (default), 256MB,
512MB, 1024MB.
VGA Core Clock control
Allows you to determine whether to manually set the VGA Core clock. (Default: Auto)
VGACoreClock(MHz)
Allows you to manually set the VGA Core clock. The adjustable range is from 300 MHz to 2000 MHz.
This item is congurable only if the VGA Core Clock control option is set to Manual.
