Gigabyte GA-A55M-DS2 User Manual

- 33 -
2-8 PC Health Status
 ResetCaseOpenStatus
Keeps or clears the record of previous chassis intrusion status. Enabled clears the record of previous
chassis intrusion status and the CaseOpened eld will show "No" at next boot. (Default: Disabled)
 CaseOpened
Displays the detection status of the chassis intrusion detection device attached to the motherboard CI
header. If the system chassis cover is removed, this eld will show "Yes", otherwise it will show "No". To
clear the chassis intrusion status record, set ResetCaseOpenStatus to Enabled, save the settings to
the CMOS, and then restart your system.
 CurrentVoltage(V)Vcore/DDR15V/+12V/Vcc3
Displays the current system voltages.
Current System/CPU Temperature
Displays current system/CPU temperature.
 CurrentCPU/SYSTEMFANSpeed(RPM)
Displays current CPU/system fan speed.
CPU Warning Temperature
Sets the warning threshold for CPU temperature. When CPU temperature exceeds the threshold,
BIOS will emit warning sound. Options are: Disabled (default), 60
o
C/140
o
F, 70
o
C/158
o
F, 80
o
C/176
o
F,
90
o
C/194
o
F.
 CPU/SYSTEMFANFailWarning
Allows the system to emit warning sound if the CPU/system fan is not connected or fails. Check the fan
condition or fan connection when this occurs. (Default: Disabled)
 CPUSmartFANControl
Enables or disables the CPU fan speed control function. Enabled allows the CPU fan to run at different
speed according to the CPU temperature. You can adjust the fan speed with EasyTune based on system
requirements. If disabled, the CPU fan runs at full speed. (Default: Enabled)
 SystemSmartFANControl
Enables or disables the system fan speed control function. Enabled allows the system fan to run at dif-
ferent speed according to the system temperature. If disabled, system fan runs at full speed. (Default:
Enabled)
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
PC Health Status
ResetCaseOpenStatus  [Disabled]
Case Opened No
Vcore 1.364V
DDR15V 1.536V
+12V 11.950V
Vcc3 3.048V
Current System Temperature 38
o
C
Current CPU Temperature 36
o
C
Current CPU FAN Speed 1962 RPM
Current SYSTEM FAN Speed 0 RPM
CPUWarningTemperature  [Disabled]
 CPUFANFailWarning  [Disabled]
 SYSTEMFANFailWarning  [Disabled]
 CPUSmartFANControl  [Enabled]
 SystemSmartFANControl  [Enabled]

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

