1-5 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
8
5j
2
11
3
15
10
1
13
12
4
9
14
7 6
j Only for the GA-C1007UN.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) IDEj
6) SATA3 0
7) SATA2 1/2
8) F_PANEL
9) F_AUDIO
10) F_USB1/2
11) COMB
12) LPT
13) BAT
14) CLR_CMOS
15) CI
