Page #8 background imageLoading...
Page #8 background image
- 8 -
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x IDE connector
j
1 x SATA 6Gb/s connector
2 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
2 x USB 2.0/1.1 headers
1 x parallel port header
1 x serial port header
1 x Clear CMOS jumper
1 x chassis intrusion header
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x serial port
1 x HDMI port
4 x USB 2.0/1.1 ports
1 x eSATA 3Gb/s connector
2 x RJ-45 ports
3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller iTE I/O Controller Chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
System fan speed control
* Whether the system fan speed control function is supported will depend on the
system cooler you install.
BIOS
2 x 32 Mbit ash
Use of licensed AMI EFI BIOS
Support for
DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a
Unique Features
Support for @BIOS
Support for Q-Flash
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune 6
* Available functions in EasyTune 6 may differ by motherboard model.
Support for Smart Recovery 2
Support for Auto Green
Support for ON/OFF Charge
j Only for the GA-C1007UN.
