- 15 -
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1
2
4
4
6
5
1210
9
11
8
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) CLR_CMOS
6) SATA2 0/1/2/3/4/5
7) BAT
8) F_PANEL
9) F_AUDIO
10) SPDIF_O
11) F_USB1/F_USB2/F_USB3/F_USB4
12) TPM
4
3
7
