- 12 -
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA3 0/1/2/3
6) F_PANEL
7) SPDIF_O
8) F_AUDIO
9) F_USB30
10) F_USB1/F_USB2
11) COM
12) CLR_CMOS
13) CI
14) BAT
1
2
5
1210
14
8
911
7
3
5
6
13
4
