1-2 ProductSpecications
CPU Support for 9th and 8th Generation Intel
®
Core
™
i9 processors/Intel
®
Core
™
i7
processors/Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors in the LGA1151 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset
Intel
®
Q370 Express Chipset
Memory
2 x DDR4 SO-DIMM socket supporting up to 32 GB of system memory
Support for DDR4 2133 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard
Graphics
Integrated Graphics Processor-Intel
®
HDGraphicssupport:
- 1xDisplayPort,supportingamaximumresolutionof4096x2304@60Hz
* Support for DisplayPort 1.2 version, HDCP 2.2, and HDR.
- 1xHDMIport,supportingamaximumresolutionof4096x2160@60Hz
* Support for HDMI 2.0 version, HDCP 2.2, and HDR.
Maximum shared memory of 1 GB
Audio
Realtek
®
ALC887 codec
High Denition Audio
2/4/5.1-channel
LAN 2 x Intel
®
GbE LAN chips (10/100/1000 Mbit)
TPM
(Note)
Inneonchip,supportingTPM2.0
Expansion Slots 1 x PCI Express x4 slot
(The PCI Express x4 slot conforms to PCI Express 3.0 standard.)
1 x M.2 Socket 1 connector for an Intel
®
CNVi or a PCIe wireless module (CNVI)
1 x full size Mini PCIe connector (MSATA_PCIE)
* The MSATA_PCIE connector can also be used as an MSATA connector.
(The Mini PCIe connector conforms to PCI Express 2.0 standard.)
Storage Interface Chipset:
- 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type
2260/2280SATAandPCIex2/x4SSDsupport)
- 2 x SATA 6Gb/s connectors
- SupportforRAID0andRAID1
Intel
®
Optane
™
MemoryReady
USB Chipset:
- 4 x USB 3.0 ports (2 ports on the back panel, 2 ports available through the
internal USB header)
- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
(Note) This feature is optional due to different regional policy.
- 6 -
To Next Page
