BIOS Setup - 36 -
CPU Thermal Monitor
(Note 1)
Enables or disables Intel CPU Thermal Monitor function, a CPU overheating protection function. When
enabled, the CPU core frequency and voltage will be reduced when the CPU is overheated. Auto lets
theBIOSautomaticallycongurethissetting.(Default:Auto)
CPU EIST Function
(Note 1)
Enables or disables Enhanced Intel SpeedStep Technology (EIST). Depending on CPU loading, Intel
EIST technology can dynamically and effectively lower the CPU voltage and core frequency to decrease
average power consumption and heat production. Auto lets the BIOS automatically configure this
setting. (Default: Auto)
Bi-Directional PROCHOT
(Note 1)
Auto  LetsBIOSautomaticallycongurethissetting.(Default)
Enabled When the CPU or chipset detects that an overheating is occurring, PROCHOT signals will
be emitted to lower CPU performance to decrease heat production.
Disabled Only allows the CPU to detect whether an overheating is occurring to emit PROCHOT
signals.
>>>>> Standard Clock Control
BCLK/DMI/PEG Clock Control
j
Enables or disables the control of CPU base clock and DMI/PCIe bus frequency. Enabled will allow the
BCLK/DMI/PEG Frequency(0.1MHz)itembelowtobecongurable.Note:Ifyoursystemfailstoboot
after overclocking, please wait for 20 seconds to allow for automated system reboot, or clear the CMOS
values to reset the board to default values. (Default: Disabled)
BCLK/DMI/PEG Frequency(0.1MHz)
j
Allows you to manually set the CPU base clock and DMI/PCIe bus frequency. The adjustable range is
from800MHzto2000MHz.ThisitemiscongurableonlyiftheBCLK/DMI/PEG Clock Control option is
enabled.
Important:ItishighlyrecommendedthattheCPUfrequencybesetinaccordancewiththeCPUspecications.
Extreme Memory Prole (X.M.P.)
(Note 2)
j
Allows the BIOS to read the SPD data on XMP memory module(s) to enhance memory performance
when enabled.
Disabled Disables this function. (Default)
Prole1  UsesProle1settings.
Prole2
(Note 2)
 UsesProle2settings.
System Memory Multiplier (SPD)
Allows you to set the system memory multiplier. Auto sets memory multiplier according to memory SPD
data. (Default: Auto)
Memory Frequency(Mhz)
 Therst memoryfrequencyvalueisthe normal operatingfrequencyof the memory being used; the
second is the memory frequency that is automatically adjusted according to the BCLK/DMI/PEG
Frequency(0.1MHz) and System Memory Multiplier settings.
(Note 1) This item is present only if you install a CPU that supports this feature. For more information about
Intel CPUs' unique features, please visit Intel's website.
(Note 2) This item is present only if you install a memory module that supports this feature.
j
Only for GA-P67-DS3-B3.

Gigabyte GA-P67-DS3-B3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7/Vista/XP
On-board graphics card	No
RAID levels	0, 1, 5, 10
Bundled software	Norton Internet Security
Ethernet interface type	Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	215 mm
Width	305 mm
