- 37 - BIOS Setup
(Note) This item is present only if you install a memory module that supports this feature.
Extreme Memory Prole (X.M.P.)
(Note)
j
, System Memory Multiplier (SPD),
Memory Frequency(Mhz)
The settings under the three items above are synchronous to those under the same items on the
Advanced Frequency Settings menu.
Performance Enhance
Allows the system to operate at three different performance levels.
Standard Lets the system operate at its basic performance level.
Turbo Lets the system operate at its good performance level. (Default)
Extreme Lets the system operate at its best performance level.
DRAM Timing Selectable (SPD)
Quick and Expert allows the Channel Interleaving, Rank Interleaving, Channel A Timing Settings,
and Channel B Timing Settingsitemstobecongurable.Optionsare:Auto(default),Quick,Expert.
Prole DDR Voltage
When using a non-XMP memory module or Extreme Memory Prole (X.M.P.) is set to Disabled, this
item will display as 1.5V. When Extreme Memory Prole (X.M.P.) is set to Prole1 or Prole2, this
item will display the value based on the SPD data on the XMP memory.
Prole VTT Voltage
The value displayed here is dependent on the CPU being used.
Channel Interleaving
Enables or disables memory channel interleaving. Enabled allows the system to simultaneously access
different channels of the memory to increase memory performance and stability. Auto lets the BIOS au-
tomaticallycongurethissetting.(Default:Auto)
Rank Interleaving
Enables or disables memory rank interleaving. Enabled allows the system to simultaneously access dif-
ferent ranks of the memory to increase memory performance and stability. Auto lets the BIOS automati-
callycongurethissetting.(Default:Auto)

Advanced Memory Settings
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Memory Settings
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

 ExtremeMemoryProle(X.M.P.)
(Note)
j
[Disabled]
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1333 1333
Performance Enhance [Turbo]
DRAM Timing Selectable (SPD) [Auto]
 ProleDDRVoltage   1.5V
 ProleVTTVoltage   1.05V
x Channel Interleaving 6 Auto
x Rank Interleaving 4 Auto
>>>>> Channel A

Channel A Timing Settings [Press Enter]
>>>>> Channel B

Channel B Timing Settings [Press Enter]
j
Only for GA-P67-DS3-B3.
