Gigabyte GA-X79-UD3 User Manual

- 8 -
GA-X79-UD3 Motherboard Block Diagram
PS/2 KB/Mouse
LGA2011 CPU
DMI 2.0
Intel
®
X79
IT8728
CPU CLK+/- (100 MHz)
4 SATA 3Gb/s
Dual BIOS
LPC
Bus
PCI Express Bus
PCI Express Bus
PCIe CLK
(100 MHz)
PCIe CLK
(100 MHz)
x1
x1
LAN
RJ45
Intel GbE LAN
Marvell
88SE9172
2 SATA 6Gb/s
PCI Express Bus
PCIe CLK
(100 MHz)
Switch
x8
x16
1 PCI Express x16
2 PCI Express x8
or
x1
2 SATA 6Gb/s
14 USB 2.0/1.1
Center/Subwoofer Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Side Speaker Out
Surround Speaker Out
CODEC
x16 x8
1 PCI
Express x8
1 PCI
Express x16
2 USB 3.0/2.0
Fresco
FL1009
PCI Express Bus
2 PCI Express x1
x1 x1
PCIe CLK
(100 MHz)
2 SATA 6Gb/s
Marvell
88SE9172
PCI Bus
1 PCI
PCI Bus
x1
2 USB 3.0/2.0
Fresco
FL1009
x1
PCIe CLK
(33 MHz)
x1
2 SATA 6Gb/s
Marvell
88SE9172
COM
DDR3 2133/1866/1600/1333/1066 MHz
4 Channel Memory

Gigabyte GA-X79-UD3 Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Quad-channel
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1200, 1300, 1333, 1500, 1600, 1666, 1800, 1866, 1900, 2000, 2133 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
USB 2.0 connectors	3
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit
eSATA ports quantity	2
USB 2.0 ports quantity	8
Audio chip	Realtek ALC898
Component for	PC
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7/Vista/XP
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	2-Way SLI, 3-Way SLI, Hybrid CrossFireX, Quad-GPU CrossFireX, Quad-GPU SLI
PCI Express slots version	3.0
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	244 mm
Width	305 mm
