Gigabyte GA-Z68P-DS3 User Manual

- 11 - Hardware Installation
USB Chipset: 
- Up to 10 USB 2.0/1.1 ports (4 ports on the back panel, 6 ports available
through the internal USB headers)
Etron EJ168 chip: 
- Up to 2 USB 3.0/2.0 ports on the back panel.
Internal
Connectors
1 x 24-pin ATX main power connector 
1 x 4-pin ATX 12V power connector 
2 x SATA 6Gb/s connectors 
4 x SATA 3Gb/s connectors 
1 x CPU fan header 
2 x system fan headers 
1 x power fan header 
1 x front panel header 
1 x front panel audio header 
1 x S/PDIF Out header 
3 x USB 2.0/1.1 headers 
1 x clearing CMOS jumper 
1 x Trusted Platform Module (TPM) header 
Back Panel
Connectors
1 x PS/2 keyboard/mouse port 
1 x parallel port 
1 x serial port 
1 x optical S/PDIF Out connector 
4 x USB 2.0/1.1 ports 
2 x USB 3.0/2.0 ports 
1 x RJ-45 port 
3 x audio jacks (Line In/Line Out/Microphone) 
I/O Controller iTE IT8728 chip 
Hardware
Monitor
System voltage detection 
CPU/System temperature detection 
CPU/System/Power fan speed detection 
CPU overheating warning 
CPU/System/Power fan fail warning 
CPU/System fan speed control 
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 2x32Mbitash 
Use of licensed AWARD BIOS 
Support for DualBIOS 
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b 

Gigabyte GA-Z68P-DS3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1300, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Parallel ports quantity	1
Motherboard chipset	Intel Z68
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows 7, Vista, XP
Parallel processing technology support	Quad-GPU CrossFireX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
LAN controller	Realtek RTL8111E
Networking features	10/100/1000 Mbps
Ethernet interface type	Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b

Weight and Dimensions

Depth	215 mm
Width	305 mm
