- 21 - Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
First make sure your devices are compliant with the connectors you wish to connect.
Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) PWR_FAN
6) BAT
7) SATA3 0/1
8) SATA2 2/3/4/5
9) F_PANEL
10) F_AUDIO
11) SPDIF_O
12) F_USB1/F_USB2/F_USB3
13) CLR_CMOS
14) PHASE LED
15) TPM
1 14
2
8
9
5
6
4
3
121541110
7
13

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte GA-Z68P-DS3 and is the answer not in the manual?

Gigabyte GA-Z68P-DS3 Specifications

General IconGeneral
Non-ECCYes
Memory voltage1.5 V
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR3-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds1300, 1333, 1600, 1866, 2133 MHz
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
USB 2.0 connectors3
Number of SATA III connectors2
Number of Parallel ATA connectors-
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
USB 2.0 ports quantity6
Parallel ports quantity1
Motherboard chipsetIntel Z68
Audio output channels7.1 channels
Motherboard form factorATX
Compatible operating systemsMicrosoft Windows 7, Vista, XP
Parallel processing technology supportQuad-GPU CrossFireX
RAID levels0, 1, 5, 10
Supported storage drive interfacesSATA, SATA II, SATA III
LAN controllerRealtek RTL8111E
Networking features10/100/1000 Mbps
Ethernet interface typeGigabit Ethernet
BIOS typeAWARD
ACPI version1.0b
Weight and Dimensions IconWeight and Dimensions
Depth215 mm
Width305 mm
