Gigabyte GA-Z68P-DS3 User Manual

BIOS Setup - 34 -
M.I.T. Current Status

This screen provides information on CPU/memory frequencies/parameters.
Advanced Frequency Settings

(Note 1) This item is present only if you install a memory module that supports this feature.
(Note 2) This item is present only if you install a CPU that supports this feature. For more information about
Intel CPUs' unique features, please visit Intel's website.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Frequency Settings
CPU Clock Ratio [31X]
CPU Frequency 3.10GHz (100x31)

Advanced CPU Core Features [Press Enter]
>>>>> Standard Clock Control
BCLK/DMI/PEG Clock Control [Disabled]
x BCLK/DMI/PEG Frequency (0.1MHz) 1000 100.0MHz
 ExtremeMemoryProle(X.M.P.)
(Note 1)
[Disabled]
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1333 1333
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

Advanced CPU Core Features

CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced CPU Core Features
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CPU Clock Ratio [31X]
CPU Frequency 3.10GHz (100x31)
Internal CPU PLL Overvoltage [Auto]
Real-Time Ratio Changes In OS
(Note 2)
[Disabled]
Intel(R) Turbo Boost Tech.
(Note 2)
[Auto]
-Turbo Ratio(1-Core)
(Note 2)
36 [Auto]
-Turbo Ratio(2-Core)
(Note 2)
34 [Auto]
-Turbo Ratio(3-Core)
(Note 2)
32 [Auto]
-Turbo Ratio(4-Core)
(Note 2)
31 [Auto]
-Turbo Power Limit(Watts) 95 [Auto]
-Core Current Limit(Amps) 97 [Auto]
CPU Cores Enabled
(Note 2)
[All]
CPU Multi-Threading
(Note 2)
[Enabled]
CPU Enhanced Halt (C1E)
(Note 2)
[Auto]
C3/C6 State Support
(Note 2)
[Auto]
CPU Thermal Monitor
(Note 2)
[Auto]
CPU EIST Function
(Note 2)
[Auto]
Bi-Directional PROCHOT
(Note 2)
[Auto]
CPU Clock Ratio
Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU
being installed.

Gigabyte GA-Z68P-DS3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1300, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Parallel ports quantity	1
Motherboard chipset	Intel Z68
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows 7, Vista, XP
Parallel processing technology support	Quad-GPU CrossFireX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
LAN controller	Realtek RTL8111E
Networking features	10/100/1000 Mbps
Ethernet interface type	Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b

Weight and Dimensions

Depth	215 mm
Width	305 mm
