Gigabyte GA-Z68P-DS3 User Manual

- 35 - BIOS Setup
(Note) This item is present only if you install a CPU that supports this feature. For more information about
Intel CPUs' unique features, please visit Intel's website.
CPU Frequency
Displays the current operating CPU frequency.
Internal CPU PLL Overvoltage
Enabled allows CPU PLL voltage to operate at a higher value. Disabled allows CPU PLL voltage to
operate at default value. AutoletstheBIOSautomaticallycongurethissetting.(Default:Auto)
Real-Time Ratio Changes in OS
(Note)
Enabled allows you to make real-time changes to the CPU clock ratio in your operating system. The
Intel Turbo Boost technology and associated items below will become unavailable. Set this item to
Disabled ifyouwanttomanuallycongureCPUTurboratiosinBIOSsetup.(Default:Disabled)
Intel(R) Turbo Boost Tech.
(Note)
Allows you to determine whether to enable the Intel CPU Turbo Boost technology. Auto lets the BIOS
automaticallycongurethissetting.(Default:Auto)
Turbo Ratio (1-Core)/(2-Core)/(3-Core)/(4-Core)
(Note)
Allows you to set the CPU Turbo ratios for different number of active cores. Auto sets the CPU Turbo
ratiosaccordingtotheCPUspecications.(Default: Auto)
Turbo Power Limit (Watts)
Allows you to set a power limit for CPU Turbo mode. When the CPU power consumption exceeds the
speciedpowerlimit,theCPUwillautomaticallyreducethecorefrequencyinordertoreducethepower.
AutosetsthepowerlimitaccordingtotheCPUspecications.(Default: Auto)
Core Current Limit (Amps)
 Allows you to set a current limit forCPUTurbomode. Whenthe CPU currentexceeds thespecied
current limit, the CPU will automatically reduce the core frequency in order to reduce the current. Auto
setsthecurrentlimitaccordingtotheCPUspecications.(Default: Auto)
CPU Cores Enabled
(Note)
Allows you to determine whether to enable all CPU cores.
All Enables all CPU cores. (Default)
1 Enables only one CPU core.
2 Enables only two CPU cores.
3 Enables only three CPU cores.
CPU Multi-Threading
(Note)
Allows you to determine whether to enable multi-threading technology when using an Intel CPU that
supports this function. This feature only works for operating systems that support multi-processor mode.
(Default: Enabled)
CPU Enhanced Halt (C1E)
(Note)
Enables or disables Intel CPU Enhanced Halt (C1E) function, a CPU power-saving function in system
halt state. When enabled, the CPU core frequency and voltage will be reduced during system halt state
to decrease power consumption. AutoletstheBIOSautomaticallycongurethissetting.(Default:Auto)
C3/C6 State Support
(Note)
Allows you to determine whether to let the CPU enter C3/C6 mode in system halt state. When enabled,
the CPU core frequency and voltage will be reduced during system halt state to decrease power con-
sumption. The C3/C6 state is a more enhanced power-saving state than C1. Auto lets the BIOS auto-
maticallycongurethissetting.(Default:Auto)

Gigabyte GA-Z68P-DS3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1300, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Parallel ports quantity	1
Motherboard chipset	Intel Z68
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows 7, Vista, XP
Parallel processing technology support	Quad-GPU CrossFireX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
LAN controller	Realtek RTL8111E
Networking features	10/100/1000 Mbps
Ethernet interface type	Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b

Weight and Dimensions

Depth	215 mm
Width	305 mm
