Gigabyte GA-Z97N-WIFI User Manual

- 11 - Hardware Installation
USB  Chipset:
- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 4-pin ATX 12V power connector
 6 x SATA 6Gb/s connectors
 1 x CPU fan header
 1 x system fan header
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.0/2.0 header
 1 x USB 2.0/1.1 header
 1 x serial port header
 1 x S/PDIF Out header
 1 x Clear CMOS jumper
 1 x chassis intrusion header
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 2 x HDMI ports
 2 x SMA antenna connectors (2T2R)
 1 x DVI-I port
 4 x USB 3.0/2.0 ports
 2 x USB 2.0/1.1 ports
 2 x RJ-45 ports
 1 x optical S/PDIF Out connector
 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
Line Out, Mic In)
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 System voltage detection
 CPU/System temperature detection
 CPU/System fan speed detection
 CPU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  2 x 64 Mbit ash
 Use of licensed AMI UEFI BIOS
 Support for DualBIOS
™
 PnP 1.0a, DMI 2.7, SM BIOS 2.7, ACPI 2.0

Gigabyte GA-Z97N-WIFI Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
USB 2.0 connectors	1
Number of SATA connectors	6
Number of Parallel ATA connectors	-
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA
HDMI version	1.4a
Headphone outputs	5
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® Z97
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	1000 MB
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	64 Mbit
Bundled software	Norton Internet Security (OEM version)\\r Intel Rapid Start Technology\\r Intel Smart Connect Technology\\r Intel Smart Response Technology\\r Intel Wireless Display

Weight and Dimensions

Width	170 mm
