Page #31 background imageLoading...
Page #31 background image
- 31 -
BIOS Setup
BIOS(Basic Input and Output System) records hardware parameters ofthe system in the CMOS on the
motherboard.ItsmajorfunctionsincludeconductingthePower-OnSelf-Test(POST)duringsystemstartup,
saving system parameters and loading operating system, etc. BIOS includes a BIOS Setup program that allows
theusertomodifybasicsystemcongurationsettingsortoactivatecertainsystemfeatures.
When the power is turned off, the battery on the motherboard supplies the necessary power to the CMOS to
keepthecongurationvaluesintheCMOS.
To access the BIOS Setup program, press the <Delete> key during the POST when the power is turned on.
To upgrade the BIOS, use either the GIGABYTE Q-Flash or @BIOS utility.
Q-Flash allows the user to quickly and easily upgrade or back up BIOS without entering the operating system.
@BIOS is a Windows-based utility that searches and downloads the latest version of BIOS from the Internet
and updates the BIOS.
Chapter 2 BIOS Setup
BecauseBIOS ashingispotentiallyrisky,if youdonotencounterproblems usingthecurrent
versionofBIOS,itisrecommendedthatyounot ashtheBIOS.Toashthe BIOS,doitwith
caution.InadequateBIOSashingmayresultinsystemmalfunction.
Itisrecommendedthatyounotalterthedefaultsettings(unlessyouneedto)topreventsystem
instability or other unexpected results. Inadequately altering the settings may result in system's
failure to boot. If this occurs, try to clear the CMOS values and reset the board to default values.
(Refertothe"LoadOptimizedDefaults"sectioninthischapterorintroductionsofthebatteryor
theclearCMOSjumperinChapter1forhowtocleartheCMOSvalues.)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte GA-Z97N-WIFI and is the answer not in the manual?

Gigabyte GA-Z97N-WIFI Specifications

General IconGeneral
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1333, 1600 MHz
Processor socketLGA 1150 (Socket H3)
Processor manufacturerIntel
Compatible processor seriesIntel® Celeron®
USB 2.0 connectors1
Number of SATA connectors6
Number of Parallel ATA connectors-
RAID levels0, 1, 5, 10
Supported storage drive interfacesSATA
HDMI version1.4a
Headphone outputs5
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Audio chipRealtek ALC892
Component forPC
Power source typeATX
Motherboard chipsetIntel® Z97
Audio output channels7.1 channels
Motherboard form factormini ITX
Maximum resolution4096 x 2160 pixels
Maximum graphics card memory1000 MB
BIOS typeUEFI AMI
ACPI version5.0
BIOS memory size64 Mbit
Bundled softwareNorton Internet Security (OEM version)\\r Intel Rapid Start Technology\\r Intel Smart Connect Technology\\r Intel Smart Response Technology\\r Intel Wireless Display
