- 21 - Hardware Installation
• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour
device and then remove it from the motherboard.
• When removing the cable, pull it straight out from the connector. Do not rock it side to side to prevent
an electrical short inside the cable connector.
Theaudiojackscanbereconguredtoperformdifferentfunctionsviatheaudiosoftware(supported
functionsmayvarybasedonhardwarespecication).IfyouinstallaSideSpeaker,youneedtoretask
other audio jack to be Side Speaker out. Only microphones still MUST be connected to the default
Mic in jack.
