Appendix
FCC Notice (U.S.A. Only)
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult a dealer or experienced TV/radio technician for help.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits.
Neither the Dealer nor the Manufacturer are responsible for any radio or television interference caused by using
otherthanrecommendedcablesandconnectorsorbyunauthorizedchangesormodificationstothisequipment.
Unauthorizedchangesormodificationscouldvoidtheuser'sauthoritytooperatetheequipment.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority
to operate the equipment.
Canada-IndustryCanada(IC):
This device complies with RSS210 of Industry Canada.
Cet appareil se conforme à RSS210 de Canada d'Industrie.
Caution: When using IEEE 802.11a wireless LAN, this product is restricted to indoor use due to its operation in the
5.15-to5.25-GHzfrequencyrange.IndustryCanadarequiresthisproducttobeusedindoorsforthefrequencyrange
of5.15GHzto5.25GHztoreducethepotentialforharmfulinterferencetoco-channelmobilesatellitesystems.High
powerradarisallocatedastheprimaryuserofthe5.25-to5.35-GHzand5.65to5.85-GHzbands.Theseradar
stations can cause interference with and/or damage to this device.
The maximum allowed antenna gain for use with this device is 6dBi in order to comply with the E.I.R.P limit for
the5.25-to5.35and5.725to5.85GHzfrequencyrangeinpoint-to-pointoperation.
ThisClassBdigitalapparatuscomplieswithCanadianICES-003,Issue4,andRSS-210,No4(Dec2000)
andNo5(Nov2001).
"To prevent radio interference to the licensed service, this device is intended to be operated indoors and away
fromwindowstoprovidemaximumshielding.Equipment(oritstransmitantenna)thatisinstalledoutdoorsis
subject to licensing."
Attention : l’utilisation d’un réseau sans fil IEEE802.11a est réstreinte à une utilisation en intérieur à cause du
fonctionementdanslabandedefréquence5.15-5.25GHz.IndustryCanadarequiertqueceproduitsoitutiliséà
l’intérieurdesbâtimentspourlabandedefréquence5.15-5.25GHzafinderéduirelespossibilitésd’interférences
nuisibles aux canaux co-existants des systèmes de transmission satellites. Les radars de puissances ont fait
l’objetd’uneallocationprimairedefréquencesdanslesbandes5.25-5.35GHzet5.65-5.85GHz.Cesstations
radar peuvent créer des interférences avec ce produit et/ou lui être nuisible.

Gigabyte GA-Z97N-WIFI Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
USB 2.0 connectors	1
Number of SATA connectors	6
Number of Parallel ATA connectors	-
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA
HDMI version	1.4a
Headphone outputs	5
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® Z97
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	1000 MB
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	64 Mbit
Bundled software	Norton Internet Security (OEM version)\\r Intel Rapid Start Technology\\r Intel Smart Connect Technology\\r Intel Smart Response Technology\\r Intel Wireless Display

Weight and Dimensions

Width	170 mm
