Gigabyte M34WQ User Manual

LCD Monitor User's Manual
-
33
-
Note: The following picture modes will be shown only when HDR function is
activated.
Exit
Move/Adjust
Enter/Conrm
Picture Mode Standard
HDR Brightness Contrast Sharpness Gamma Color Temperature
85 50 5 OFF Normal
Gaming
Display
System
PIP/PBP
Language
Reset All
Save Settings
Light Enhance
Dark Enhance
Reset Picture
HDR
Color Enhance
Item Description
HDR Light Enhance: Enhance the Brightness performance.
Color Enhance: Enhance the Color performance.
Dark Enhance: Enhance the Darkness performance.
Reset Picture: Reset all Picture settings to the default
settings.

Gigabyte M34WQ Specifications

General

Color depth	8 bit
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Viewable size, vertical	334.8 mm
sRGB coverage (typical)	117 %
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	799.8 mm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	3440 x 1440
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 400
RMS rated power	3 W
Number of speakers	2
Product color	Black
Market positioning	Gaming
DisplayPort version	1.4
Headphone connectivity	3.5 mm
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	127 W
Power consumption (off)	0.3 W
Power consumption (typical)	- W
Power consumption (PowerSave)	0.5 W
Cables included	DisplayPort, HDMI, USB
Package type	Box
Package depth	198 mm
Package width	1060 mm
Package height	527 mm
Package weight	13470 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	244.3 mm
Width (with stand)	817.7 mm
Height (with stand)	548.8 mm
Weight (with stand)	10220 g
Depth (without stand)	67.5 mm
Height (without stand)	368.7 mm
Weight (without stand)	7050 g
