Gigabyte M34WQ User Manual

LCD Monitor User's Manual
-
34
-
Display
Congure the display screen related settings.
Exit
Move/Adjust
Enter/Conrm
Picture Mode Standard
SDR Brightness Contrast Sharpness Gamma Color Temperature
85 50 5 OFF Normal
Gaming
Display
System
PIP/PBP
Language
Reset All
Save Settings
HDMI 1
HDMI 2
Type-C
DisplayPort
RGB PC Range
Input
Overscan
Item Description
Input Select the input source.
RGB PC Range Select an appropriate RGB range setting or let the
monitor to detect it automatically.
OverScan When this function is enabled, it slightly enlarges
the input image to hide the outermost edges of the
image.

Gigabyte M34WQ Specifications

General

Color depth	8 bit
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Viewable size, vertical	334.8 mm
sRGB coverage (typical)	117 %
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	799.8 mm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	3440 x 1440
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 400
RMS rated power	3 W
Number of speakers	2
Product color	Black
Market positioning	Gaming
DisplayPort version	1.4
Headphone connectivity	3.5 mm
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	127 W
Power consumption (off)	0.3 W
Power consumption (typical)	- W
Power consumption (PowerSave)	0.5 W
Cables included	DisplayPort, HDMI, USB
Package type	Box
Package depth	198 mm
Package width	1060 mm
Package height	527 mm
Package weight	13470 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	244.3 mm
Width (with stand)	817.7 mm
Height (with stand)	548.8 mm
Weight (with stand)	10220 g
Depth (without stand)	67.5 mm
Height (without stand)	368.7 mm
Weight (without stand)	7050 g
