Item Code Description
1 LED_BMC BMC Firmware Readiness LED
2 SW_ID ID Button with LED
3 LAN3_4 GbE LAN Port #3/#4
4 USB31_MLAN Server Management LAN Port (Top)/USB 3.1 Ports (Bottom)
5 COM_VGA Serial Port (Top)/VGA Port (Bottom)
6 CPU_FAN CPU Fan Connector
7 BATTERY Battery Socket
8 PMBUS PMBus Connector
9 ATX_12V 2x4 Pin 12V Power Connector
10 ATX 2x12 Pin Main Power Connector
11 SYS_FAN5 System Fan Connector #5
12 SYS_FAN4 System Fan Connector #4
13 SYS_FAN3 System Fan Connector #3
14 SYS_FAN2 System Fan Connector #2
15 SYS_FAN1 System Fan Connector #1
16 SPI_TPM TPM Connector
17 SATA_0_1 SATA III 6Gb/s Connector #0/#1
18 SATA_2_3 SATA III 6Gb/s Connector #2/#3
19 SATA5 SATA III 6Gb/s Connector #5
20 SATA4 SATA III 6Gb/s Connector #4
21 USB_A Vertical USB 2.0 Connector
22 FP_1 Front Panel Header
23 F_USB3_1 Front Panel USB 3.1 Connector
24 F_USB2_1 Front Panel USB 2.0 Connector
25 IPMB IPMB Connector
26 BP_1 HDD Back Plane Board Connector
27 PCIEX4 PCIe x4 Slot (Gen4 x4)
28 M2M_1 M.2 Slot (PCIe Gen3 x4, Support NGFF-2280)
29 PCIEX16 PCIe x16 Slot (Gen4 x16)
