Gigabyte MC12-LE0 User Manual

- 61 -
BIOS Setup
Parameter
Description
Data Eye
(Continued)

Aggressor Channel
– This item helps read the aggressors channels.
– Options available: Disabled, 1 Aggressor Channel, 3 Aggressor
Channels, 7 Aggressor Channels. Default setting is 1 Aggressor
Channel.

Aggressor Static Lane Control
– Enable/Disable the Aggressor Static Lane Control function.
– Options available: Enabled, Disabled. Default setting is Disabled.

Aggressor Static Lane Select Upper 32 bits
(Note1)

Aggressor Static Lane Select Lower 32 bits
(Note1)

Aggressor Static Lane Select ECC
(Note1)

Aggressor Static Lane Value
(Note1)

Target Static Lane Control
– Enable/Disable the Target Static Lane Control function.
– Options available: Enabled, Disabled. Default setting is Disabled.

Target Static Lane Select Upper 32 bits
(Note2)

Target Static Lane Select Lower 32 bits
(Note2)

Target Static Lane Select ECC
(Note2)

Target Static Lane Value
(Note2)

Worst Case Margin Granularity
– Options available: Per Chip Select, Per Nibble. Default setting is Per
Chip Select.

Read Voltage Sweep Step Size
– Options available: 1, 2, 4. Default setting is 1.

Read Timing Sweep Step Size
– Options available: 1, 2, 4. Default setting is 1.

Write Voltage Sweep Step Size
– Options available: 1, 2, 4. Default setting is 1.

Write Timing Sweep Step Size
– Options available: 1, 2, 4. Default setting is 1.
(Note1) ThisitemiscongurablewhenAggressor Static Lane Control is set to Enabled.
(Note2) ThisitemiscongurablewhenTarget Static Lane Control is set to Enabled.
