- 60 -
BIOS Setup
Parameter
Description
Assert ADR on S5
Enable/Disable Assert ADR on S5.
Options available: Enabled, Disabled. Default setting is Disabled.
Get Memory Timing
Auto is the detected SPD value and use it, otherwise use BIOS Build-in.
Options available: Auto, BIOS Build-in. Default setting is BIOS Build-in.
Memory Topology
Press [Enter] to view memory topology with DIMM population
information.
Memory Map
Press[Enter]tocongureadvanceditems.
Volatile Memory Mode
– Selects 1LM or 2LM mode for volatile memory.
– Options available: 1LM, 2LM. Default setting is 2LM.
MemoryRASConguration
Press[Enter]tocongureadvanceditems.
Mirror Mode
(Note)
– Mirror Mode will set entire 1LM memory in system to be
mirrored, consequently reducing the memory capacity by half.
Enables the Mirror Mode will disable the XPT Prefetch.
– Options available: Disabled, Full Mirror Mode, Partial Mirror
Mode. Default setting is Disabled.
Partial Mirror 1 Size (GB)
– Selects multiplier of 1GB for the size of the SAD to be created.
Correctable Error Threshold
– Correctable Error Threshold (0x01-0x7fff) used for sparing, and
leaky bucket.
– Press the <+> / <-> keys to increase or decrease the desired
values.
Trigger SW Error Threshold
(Note)
– Enable/Disable Sparing trigger SW Error Match Threshold.
– Options available: Disabled, Enabled. Default setting is
Disabled.
SW Per Bank Threshold
– SW Per Bank Threshold (1-0x7FFF) used for DDR bank level
error.
– Press the <+> / <-> keys to increase or decrease the desired
values.
SW Correctable Error Time Window
– SW Correctable Error time window based interface in hour (0-24).
– Press the <+> / <-> keys to increase or decrease the desired
values.
Leaky bucket time window based interface
– Enable/Disable leaky bucket time window based interface.
– Options available: Disabled, Enabled. Default setting is
Disabled.
(Note) Advanceditemspromptwhenthisitemisdened.
To Next Page
