- 91 - BIOS Setup
Parameter Description
DRAM Memory Mapping
Press [Enter] for more options

Chipselect Interleaving
– Interleave memory blocks across the DRAM chip slects for node 0
– Options available: Disabled/Auto. Default option is Auto.

BankGroupSwap
– Congures the BankGroupSwap. BankGroupSwap (BGS) is a
memory mapping option in AGESA that alters how applications get
assigned to physical locations within the memory modules. When
this option sets to Auto, it is null.
– Options available: Enabled/Disabled/Auto. Default option is Auto.

BankGroupSwapAlt
– Congures the BankGroupSwapAlt.
– Options available: Enabled/Disabled/Auto. Default option is Auto.

Address Hash Bank
– Enable or disable bank address hashing.
– Options available: Disabled/Enabled/Auto. Default option is Auto.

Address Hash CS
– Enable or disable CS address hashing.
– Options available: Auto/Enabled/Disabled. Default option is Auto.

Address Hash Rm
– Enable or disable RM address hashing.
– Options available: Auto/Enabled/Disabled. Default option is Auto.

SPD Read Optimization
– Enable or disable SPD Read Optimization. Enabled = SPD reads
are skipped for Reserved elds and most of upper 256 Bytes,
Disabled = read all 512 SPD Bytes.
– Options available: Auto/Enabled/Disabled. Default option is Auto.
NVDIMM Press [Enter] for more options.
Memory MBIST
Press [Enter] for more options

MBIST Enable
– Enable or disable Memory MBIST.
– Options available: Disabled/Enabled. Default option is Disabled.

Data Eye
– Press [Enter] for more options.
