& SMT Mode
Allows you to enable or disable the CPU Simultaneous Multi-Threading technology. This feature only works
for operating systems that support multi-processor mode. Auto lets the BIOS automatically congure this
setting. (Deault: Auto)
& AMD CPU fTPM
Enables or disables the TPM 2.0 unction integrated in the AMD CPU. (Deault: Disabled)
& Extreme Memory Profle (X.M.P.)
(Note)
Allows the BIOS to read the SPD data on XMP memory module(s) to enhance memory perormance when
enabled.
Disabled Disables this unction. (Deault)
Prole1 Uses Prole 1 settings.
Prole2
(Note)
Uses Prole 2 settings.
& XMP High Frequency Support
(Note)
Allo ws you to select the compatib ility level or high-requency memory. This item i s congurable only
when Extreme Memory Profle (X.M.P.) is set to Profle1 or Pro fle2. (Deault: Auto)
& System Memory Multiplier
Allows you to set the system memory multiplier. Auto sets memory multiplier according to memory SPD
data. (Deault: Auto)
Advanced Memory Settings
Memory Subtimings
d Standard Timing Control, Advanced Timing Control, CAD Bus Setup Timing, CAD Bus
Drive Strength, Data Bus Confguration
These sections provide memory timing settings. Note: Your system may become unstable or fail to boot
after you make changes on the memory timings. If this occurs, please reset the board to default values by
loading optimized deaults or clearing the CMOS values.
SPD Info
Displays inormation on the installed memory.
& CPU Vcore/Dynamic Vcore(DVID)/VCORE SOC/Dynamic VCORE SOC(DVID)/CPU VDD18/
CPU VDDP/PM_1VSOC/PM_1V8/DRAM Voltage (CH A/B)
These items allow you to adjust the CPU Vcore and memory voltages.
Advanced Voltage Settings
This submenu allows you to congure Load-Line Calibration level, over-voltage protection level, over-current
protection level, and PWM frequency.
(Note) This item is present only when you install a CPU and a memory module that support this feature.
- 28 -
