Gigabyte X570 AORUS ELITE WIFI User Manual

 USB Confguration
& Legacy USB Support
Allows USB keyboard/mouse to be used in MS-DOS. (Deault: Enabled)
& XHCI Hand-off
Determines whether to enable XHCI Hand-o eature or an operating system without XHCI Hand-o
support. (Deault: Enabled)
& USB Mass Storage Driver Support
Enables or disables support or USB storage devices. (Deault: Enabled)
& Port 60/64 Emulation
Enables or disables emulation of I/O ports 64h and 60h. This should be enabled for full legacy support
or USB keyboards/mice in MS-DOS or in operating system that does not natively support USB devices.
(Deault: Disabled)
& Mass Storage Devices
Displays a list o connected USB mass storage devices. This item appears only when a USB storage device
is installed.
 NVMe Confguration
Displays inormation on your M.2 NVME PCIe SSD i installed.
 SATA Confguration
& SATA Mode
Enables or disables RAID or the SATAcontrollers integrated in the Chipset or congures the SATAcontrollers
to AHCI mode.
RAID Enables RAID or the SATA controller.
AHCI Congures the SATA controllers to AHCI mode. Advanced Host Controller Interace
(AHCI) is an interace specication that allows the storage driver to enable advanced
Serial ATA eatures such as Native Command Queuing and hot plug. (Deault)
& NVMe RAID mode
Allows you to determine whether to use your M.2 NVMe PCIe SSDs to congure RAID. (Deault: Disabled)
& SATA Port 0/1/2/3/4/5 (SATA3 0, 1, 2, 3, 4, 5 Connectors)
Displays the inormation o the connected SATA device(s).
` Network Stack Confguration
& Network Stack
Disables or enables booting rom the network to install a GPT ormat OS, such as installing the OS rom
the Windows Deployment Services server. (Deault: Disabled)
& Ipv4 PXE Support
Enables or disables IPv4 PXE Support. This item is congurable only when Network Stack is enabled.
& Ipv4 HTTP Support
Enables or disables HTTP boot support or IPv4. This item is congurable only when Network Stack is
enabled.
& Ipv6 PXE Support
Enables or disables IPv6 PXE Support. This item is congurable only when Network Stack is enabled.
& Ipv6 HTTP Support
Enables or disables HTTP boot support or IPv6. This item is congurable only when Network Stack is
enabled.
- 31 -

Gigabyte X570 AORUS ELITE WIFI Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Audio chip	Realtek ALC1200
Cooling type	Active
Component for	PC
Power source type	ATX
Motherboard chipset	AMD X570
Audio output channels	5.1 channels
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000 MHz
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
HDD size	2.5/3.5 \
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	16384 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
Number of M.2 (M) slots	2
Number of SATA II connectors	0
Number of SATA III connectors	6
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Bundled software	Norton Internet Security (OEM version) cFosSpeed

Weight and Dimensions

Depth	244 mm
Width	305 mm
