Gigabyte X570 AORUS ELITE WIFI - Page 9

Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x water cooling CPU fan header
 2 x system fan headers
 2 x addressable LED strip headers
 2 x RGB LED strip headers
 1 x CPU cooler LED strip/RGB LED strip header
 2 x M.2 Socket 3 connectors
 6 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB Type-C
™
header, with USB 3.2 Gen 2 support
 2 x USB 3.2 Gen 1 headers
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2. 0_S
module only)
 1 x Clear CMOS jumper
 1 x Q-Flash Plus button
Back Panel
Connectors
 4 x USB 2.0/1.1 ports
 2 x SMA antenna connectors (1T1R)j
 1 x HDMI port
 4 x USB 3.2 Gen 1 ports
 2 x USB 3.2 Gen 2 Type-A ports (red)
 1 x RJ-45 port
 1 x optical S/PDIF Out connector
 5 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling fow rate detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the fan you install.
BIOS  1 x 128 Mbit fash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WM 2.0, SM BIOS 2.7, ACPI 5.0
j Only for the X570 AORUS ELITE WIFI.
- 9 -
