20
www.gigaipc.com
No Code Description
9 SATA2, 3, 4, 5 SATA 6 Gb/s Connector x 4
10 Battery Battery Connector
11 FP_ Audio Front Panel Audio Header
12 SPKR Speaker out Connector
13 M2E M.2 Slot, E-Key, Supports NGFF-2230
14 PCIEX8 1 x PCIe x16 (Gen3 x8 bus) slot
15 CPU_FAN CPU FAN Connector
16 FUSB2_1 USB 2.0 Header
16 FUSB2_2 USB 2.0 Header
17 SYS_FAN System Fan Connector
18 LSW
LVDS Resolution Jumper
19 EDP
Embedded Display Port connector
20 BKL_CN
Back Light Brightness Control Connector
21 LVDS LVDS Connector
22 SYS_PANEL System Panel Header
23 GPIO_CNT General purpose input/out Connector
24 COM1 COM header RS232/422/485 & 5V/12V/RI
25 JCOM1
COM1 RI# pin RI#/5V/12V Select
26
AT_CN
AT/ATX power mode select jumper
27 COM2
COM header RS232
28 FUSB2_3 USB 2.0 Header
29 ATX_CTL
ATX Control Header, Support PS-ON Signal of
Power Supply Unit
To Next Page
