Thin Mini-ITX Motherboard iTXL-Q47EA (MQ47EAT-SI)
2.2.13 SYS_FAN (System Fan Connector)
17
Pin 1
System FAN
Pin No. Definition
1
G
N
D
2
1
2
V
3
S
e
n
s
e
4
P
W
M
Connector PN Vendor
744-81-045R11 PINREX
WF04R22RJQ105 HORNGTONG
