Gigaset E310 - Page 61

59
Appendix
Gigaset E310/E310A / Great Britain / A31008-M2301-L101-1-7619 / appendix.fm / 26.07.2011
Version 5, 03.04.2011
General specifications Pin connections on the
telephone jack
DECT standard Supported
GAP standard Supported
No. of channels 60 duplex channels
Radio frequency
range
1880–1900 MHz
Duplex method Time multiplex,
10 ms frame length
Repeat frequency
of the transmission
pulse
100 Hz
Length of the
transmission pulse
370 μs
Channel grid 1728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission
power
10 mW
average power
per channel,
250 mW pulse
power
Range Up to 300 m out-
doors, up to 50 m
indoors
Base power supply 230 V ~/50 Hz
Ambient condi-
tions for operation
+5°C to +45°C, 20%
to 75% relative
humidity
Dialling mode DTMF (tone dial-
ling)/PD (pulse
dialling)
1unused
2unused
3a
4b
5unused
6unused
3
2
1
4
5
6
