Template Module, Version 1.2, 11.09.2018,
Specifications
Gigaset E560A / LUG US en / A31008-M2728-R301-1-7619 / appendix_technical_Whale nach Widex.fm / 1/21/19
62
en fr es
Specifications
Batteries
The device is supplied with two approved batteries.
Handset operating times/charging times
The operating time of the telephone depends on the capacity of the battery, its age and the way it is used. (All
times are maximum possible times.)
Base power consumption
General specifications
Technology: Nickel-metal-hydride (NiMH)
Size: AAA (Micro, HR03)
Voltage: 1.2V
Capacity: 750 mAh
Standby time (hours) * 320 * / 200 **
Talktime (hours) 14
Operating time for 1.5 hours of calls per day (hours) * 130 * / 100 **
Charging time in base (hours) 9
Charging time in charging cradle (hours) 7.5
*Eco Mode deactivated, without display backlight in idle status
**Eco Mode activated, without display backlight in idle status
In standby mode
• Handset in charging cradle
• Handset away from charging cradle
approx. 0.70 W
approx. 0.50 W
During a call approx. 0.70 W
DECT standard DECT 6.0
No. of channels 30 duplex channels
Radio frequency range 1920 - 1930MHz
Duplex method Time multiplex, 10 ms frame length
Pulse repetition rate 100 Hz
Pulse transmission length 370 μs
Channel grid 1728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 5 mW average power per channel,
120 mW pulse power
Range Up to 100 ft indoors, up to 700 ft outdoors
