MDE-4327B Encore® Canopy Light Kit (M03225K001) Installation Instructions · October 2015
The Advantage
®
Series, Encore
®
, Eclipse
®
,
Gilbarco
®
, and Legacy
®
are registered trademarks of Gilbarco Inc. Channellock
®
is a registered
trademark of Channellock
®
Inc. GOLD
SM
is a service mark of Gilbarco Inc. PEM
®
is a registered trademark of PennEngineering and
Manufacturing Corporation. Unilet
®
is a registered trademark of Appleton GRP LLC.
Installing Encore Canopy Light Kit
11 Carefully insert the wires and then the other end of the conduit into the hole. Tighten the
locking nuts that secure the conduit to the cover of the dispenser.
Note: Electrical connections will be made by a licens
ed electrician and light tested for correct
operation upon powering up the dispensers.
12 Reinstall the sheathing on the unit.
13 After the electrician has completed the electrical connections, the dispensers can be returned to
an operational condition and the lights tested for correct operation according to the start-up
processes outlined in MDE-3985 Encore Installation Manual.
