24
1. Click or press [UP] [DOWN] to turn page up and down.
2. Click
to save the current settings and exit this interface into the main menu, click
to exit without save.
3. BackLight: select "OFF" and confirm it, the back light will close and device will enter the
power-save mode. Then press any a key on the panel to open the back light.
4. Power alarm: when it is enabled, system can alarm every 10s when the charge of battery is less
than 5% without AC power source.
5. Key voice: when it is enabled, key can make sound after device is started. Otherwise it is the
silence mode.
6. Language: can select Chinese or English.
7. Infor input: when it is enabled, you have to enter the interface "Set Patient" as Fig.7-12
before print or save.
Fig. 7-12
(1) switch setting information by [UP] [DOWN] on the panel.
(2) select the item you want to set, then touch the keyboard on the screen or press [Confirm] on
the panel and move focus to the keyboard to set current information. Click
to delete
the input. Click
to confirm your setting .
(3) click
to save the setting and print. Click to print without save.
Attention: (a) you can click directly or press [LEFT] [RIGHT] to set sex without keyboard.
(b) the length of name is no more than 7.
(c) age <200.
(d) weight(kg)<200
8. USB-mode
(1) this item is disabled when USB is not connected as Fig.7-10.
(2) this item is enabled when USB is connected. "Store" or "Sync" can be selected.
