Figure 4.7 SpO
2
data list screen
In this screen, the first column is the patient ID, the second column is SpO
2
recording time, the third column is SpO
2
value, and the fourth column is pulse rate (measured by SpO
2
module).
Operating instruction:
Ø Short press the Up " " or Down " " key to scroll to previous or next page for view other SpO
2
records.
Ø Short press the Print " " key to print the current SpO
2
list.
Ø Long press the OK " " key to bring up a dialogue for deleting data records, where the user can choose to
delete all SpO
2
data records.
4.7 Alarm Event List Screen
The Alarm Event List screen is as shown in Figure 4.8.
Figure 4.8Alarm event list
In this screen, the first column is the time that the alarm occurred (format is month-day hour:minute), the second column
is the event description, the third column is the onset value, and the fourth column is the high/low limit value.
Ø Short press the “ ” or “ ” key to scroll to previous/next page for view other alarm events. Note: if the
event description is too long to be shown, pressing the OK key can show the full description, but the third and
fourth column will not be displayed.
Ø Short press the print " " key to print the event list of the current page.
