Chapter 3 Preparing Work before Using
3.1 Electrode Placement
Notice:
The placement of electrode is the basic of holter recorder collecting ECG data signal. The
quality and position of electrode affect the quality of ECG signal. Please read this chapter
carefully before first operation.
The conductive part (applied part) of electrode should not contact with other conductive
parts or the earth.
Signal input/output part can be connected with the specified instrument only, please
contact our company for any replacement.
Position of the electrode placement is shown (as Fig.3-1).
Fig.3-1
