4
The left window is the template window. Every button is a template. The letter in the button
represents the type (for example: V means ventricular premature beat, S means atrial premature
beat), the percentage means what percentage this kind is in the total. No percentage means no
wave.
V: ventricular premature beat module
AF:atrial flutter module
S: supra premature beat module
Af: atrial fibrillation module
N: normal beat module
VF: ventricular flutter module
L: pause module
Vf: ventricular fibrillation module
O: Interference module
The top right window is display window for the selected template in the template cluster, which
displays every waveform.
The bottom right window is the waveform show window, which displays the detailed
information of the waveform which the mouse is pointing.
